Metallurgy, art and science of extracting metals from their ores and modifying the metals for use. Metallurgy customarily refers to commercial as opposed to laboratory methods. It also concerns the chemical, physical, and atomic properties and structures of metals and the principles whereby metals are combined to form alloys.
History Of Metallurgy
The present-day use of metals is the culmination of a long path of development extending over approximately 6,500 years. It is generally agreed that the first known metals were gold, silver, and copper, which occurred in the native or metallic state, of which the earliest were in all probability nuggets of gold found in the sands and gravels of riverbeds. Such native metals became known and were appreciated for their ornamental and utilitarian values during the latter part of the Stone Age.
Gold can be agglomerated into larger pieces by cold hammering, but native copper cannot, and an essential step toward the Metal Age was the discovery that metals such as copper could be fashioned into shapes by melting and casting in molds; among the earliest known products of this type are copper axes cast in the Balkans in the 4th millennium BCE. Another step was the discovery that metals could be recovered from metal-bearing minerals. These had been collected and could be distinguished on the basis of colour, texture, weight, and flame colour and smell when heated. The notably greater yield obtained by heating native copper with associated oxide minerals may have led to the smelting process, since these oxides are easily reduced to metal in a charcoal bed at temperatures in excess of 700 °C (1,300 °F), as the reductant, carbon monoxide, becomes increasingly stable. In order to effect the agglomeration and separation of melted or smelted copper from its associated minerals, it was necessary to introduce iron oxide as a flux. This further step forward can be attributed to the presence of iron oxide gossan minerals in the weathered upper zones of copper sulfide deposits.
In many regions, copper-arsenic alloys, of superior properties to copper in both cast and wrought form, were produced in the next period. This may have been accidental at first, owing to the similarity in colour and flame colour between the bright green copper carbonate mineral malachite and the weathered products of such copper-arsenic sulfide minerals as enargite, and it may have been followed later by the purposeful selection of arsenic compounds based on their garlic odour when heated.
Arsenic contents varied from 1 to 7 percent, with up to 3 percent tin. Essentially arsenic-free copper alloys with higher tin content—in other words, true bronze—seem to have appeared between 3000 and 2500 BCE, beginning in the Tigris-Euphrates delta. The discovery of the value of tin may have occurred through the use of stannite, a mixed sulfide of copper, iron, and tin, although this mineral is not as widely available as the principal tin mineral, cassiterite, which must have been the eventual source of the metal. Cassiterite is strikingly dense and occurs as pebbles in alluvial deposits together with arsenopyrite and gold; it also occurs to a degree in the iron oxide gossans mentioned above.
While there may have been some independent development of bronze in varying localities, it is most likely that the bronze culture spread through trade and the migration of peoples from the Middle East to Egypt, Europe, and possibly China. In many civilizations the production of copper, arsenical copper, and tin bronze continued together for some time. The eventual disappearance of copper-arsenic alloys is difficult to explain. Production may have been based on minerals that were not widely available and became scarce, but the relative scarcity of tin minerals did not prevent a substantial trade in that metal over considerable distances. It may be that tin bronzes were eventually preferred owing to the chance of contracting arsenic poisoning from fumes produced by the oxidation of arsenic-containing minerals.
As the weathered copper ores in given localities were worked out, the harder sulfide ores beneath were mined and smelted. The minerals involved, such as chalcopyrite, a copper-iron sulfide, needed an oxidizing roast to remove sulfur as sulfur dioxide and yield copper oxide. This not only required greater metallurgical skill but also oxidized the intimately associated iron, which, combined with the use of iron oxide fluxes and the stronger reducing conditions produced by improved smelting furnaces, led to higher iron contents in the bronze.
It is not possible to mark a sharp division between the Bronze Age and the Iron Age. Small pieces of iron would have been produced in copper smelting furnaces as iron oxide fluxes and iron-bearing copper sulfide ores were used. In addition, higher furnace temperatures would have created more strongly reducing conditions (that is to say, a higher carbon monoxide content in the furnace gases). An early piece of iron from a trackway in the province of Drenthe, Netherlands, has been dated to 1350 BCE, a date normally taken as the Middle Bronze Age for this area. In Anatolia, on the other hand, iron was in use as early as 2000 BCE. There are also occasional references to iron in even earlier periods, but this material was of meteoric origin.
Once a relationship had been established between the new metal found in copper smelts and the ore added as flux, the operation of furnaces for the production of iron alone naturally followed. Certainly, by 1400 BCE in Anatolia, iron was assuming considerable importance, and by 1200–1000 BCE it was being fashioned on quite a large scale into weapons, initially dagger blades. For this reason, 1200 BCE has been taken as the beginning of the Iron Age. Evidence from excavations indicates that the art of iron making originated in the mountainous country to the south of the Black Sea, an area dominated by the Hittites. Later the art apparently spread to the Philistines, for crude furnaces dating from 1200 BCE have been unearthed at Gerar, together with a number of iron objects.
Smelting of iron oxide with charcoal demanded a high temperature, and, since the melting temperature of iron at 1,540 °C (2,800 °F) was not attainable then, the product was merely a spongy mass of pasty globules of metal intermingled with a semiliquid slag. This product, later known as bloom, was hardly usable as it stood, but repeated reheating and hot hammering eliminated much of the slag, creating wrought iron, a much better product.
The properties of iron are much affected by the presence of small amounts of carbon, with large increases in strength associated with contents of less than 0.5 percent. At the temperatures then attainable—about 1,200 °C (2,200 °F)—reduction by charcoal produced an almost pure iron, which was soft and of limited use for weapons and tools, but when the ratio of fuel to ore was increased and furnace drafting improved with the invention of better bellows, more carbon was absorbed by the iron. This resulted in blooms and iron products with a range of carbon contents, making it difficult to determine the period in which iron may have been purposely strengthened by carburizing, or reheating the metal in contact with excess charcoal.
Carbon-containing iron had the further great advantage that, unlike bronze and carbon-free iron, it could be made still harder by quenching—i.e., rapid cooling by immersion in water. There is no evidence for the use of this hardening process during the early Iron Age, so that it must have been either unknown then or not considered advantageous, in that quenching renders iron very brittle and has to be followed by tempering, or reheating at a lower temperature, to restore toughness. What seems to have been established early on was a practice of repeated cold forging and annealing at 600–700 °C (1,100–1,300 °F), a temperature naturally achieved in a simple fire. This practice is common in parts of Africa even today.
By 1000 BCE iron was beginning to be known in central Europe. Its use spread slowly westward. Iron making was fairly widespread in Great Britain at the time of the Roman invasion in 55 BCE. In Asia iron was also known in ancient times, in China by about 700 BCE.
